SK 50
for shell-type milling
for shell-type milling
Catalogue no.
Form/DIN
Accessories
Features
d
1
l
3
A d
3
d
4
d
2
l
2
l
1
A
l
1
d
3
d
1
d
4
l
3
d
2
Ø 17
45°
Ø 101,6
bore diam. -Ø 22
200 22 740 diam.
22
200 233 48 78 diam.
50
direct spindle
mounting
-
38 B, D, H, L
250 22 740 diam.
22
250 283 48 82 diam.
50
direct spindle
mounting
-
38 B, D, H, L
300 22 740 diam.
22
300 333 48 86 diam.
50
direct spindle
mounting
-
38 B, D, H, L
350 22 740 diam.
22
350 383 48 90 diam.
50
direct spindle
mounting
-
38 B, D, H, L
400 22 740 diam.
22
400 433 48 95 diam.
50
direct spindle
mounting
-
38 B, D, H, L
bore diam. -Ø 27
200 27 740 diam.
27
200 233 62 78 diam.
50
direct spindle
mounting
-
38 C, E, I, L
250 27 740 diam.
27
250 283 62 82 diam.
50
direct spindle
mounting
-
38 C, E, I, L
300 27 740 diam.
27
300 333 62 86 diam.
50
direct spindle
mounting
-
38 C, E, I, L
350 27 740 diam.
27
350 383 62 90 diam.
50
direct spindle
mounting
-
38 C, E, I, L
400 27 740 diam.
27
400 433 62 95 diam.
50
direct spindle
mounting
-
38 C, E, I, L
bore diam. -Ø 32
150 32 740 diam.
32
150 183 85 98 diam.
50
direct spindle
mounting
-
38 C, F, J, L
200 32 740 diam.
32
200 233 85 98 diam.
50
direct spindle
mounting
-
38 C, F, J, L
250 32 740 diam.
32
250 283 90 105 diam.
50
direct spindle
mounting
-
38 C, F, J, L
300 32 740 diam.
32
300 333 90 110 diam.
50
direct spindle
mounting
-
38 C, F, J, L
350 32 740 diam.
32
350 383 90 117 diam.
50
direct spindle
mounting
-
38 C, F, J, L
400 32 740 diam.
32
400 433 90 124 diam.
50
direct spindle
mounting
-
38 C, F, J, L
• flange contact surfaces for direct mounting on the machine spindle
• anchor points made according to DIN 1830 for attaching
to milling spindle heads according to DIN 2079
• highest degree of stability and rigidity with long projections
or difficult machining tasks
1 / 2
▸
Direct spindle mounting
