THE POKOLM
ARBOR SYSTEM
The optimum solution for your application
ARBORS (TAPERED) for THREA-
DED SHANK END MILLS
ARBORS for THREAD-
CONNECTIONS CYLINDRICAL
REDUCTION SLEEVES
with MORSE TAPER ADAPTERS
ARBORS for SHELL TYPE MIL-
LING CUTTER BODIES
ARBORS with
DIRECT SPINDLE MOUNTING
SHRINKING ARBORS
STANDARD STYLE
uu
rigid, low-cost standard design
uu
large variety of types and lengths provides
additional flexibility by using extensions
and reductions
uu
gaining rigidity by avoiding unnecessary
interfaces
uu
milling in shallow to deep profiles, for
small milling cutter bodies up to 42 mm
diam.
uu
slim shape
uu
additional rigidity by avoiding unnecessa-
ry interfaces
uu
where needed: additional flexibility with
extensions and reductions
uu
medium machining depths, especially on
deep vertical walls for small milling cutter
bodies up to 42 mm diam.
uu
Morse taper adapters for threaded shank
end mill bodies and for shrinking proces-
ses available for solid carbide tools
uu
fast and flexible tool change
uu
modular design allows machining of deep
slots and cavities
uu
for standard milling operations with nor-
mal rigidity and accuracy requirements,
for milling cutter bodies up to 42 mm
diam.
uu
slim style with 3° draft angle in direction
of collar
uu
direct shrink-grip of solid carbide tooling
uu
additional rigidity by avoiding unnecessa-
ry interfaces
uu
improved concentricity
uu
combinable with solid carbide and dense
antivibration adapters
uu
machining situations in narrow space
conditions for solid carbide end mills up
to 25 mm diam., and when combined
with solid carbide or dense antivibration
adapters even for milling cutter bodies
with up to 42 mm diam.
uu
rigid variant, in particular for roughing or
pre-finishing operations with large cutter
diameters and a large variety of designs
uu
additional rigidity by avoiding unnecessa-
ry interfaces
uu
shallow to deep machining situations for
pre-finishing and rough machining, for
milling cutter diameters from 42 mm to
125 mm and larger
uu
extremely rigid style through direct spind-
le mounting
uu
excellent machining conditions in deep
slots or cavities
uu
additional rigidity by avoiding interfaces
uu
deep and extremely deep machining situ-
ations on SK 50 machines which require
extreme rigidity, for milling cutter diame-
ters from 52 to 125 mm
Arbor System Advantages
Recommended applications
The Pokolm arbor system
