NOTE ON BALANCE QUALITY:
For all arbors, the balance quality is
G 6.3 at 18,000 rpm
This value is reliably achieved, even if the
COOLCAP
®
caps are repeatedly loosened and replaced.
Furthermore, exchanging the caps between caps for air cooling and caps for emulsion cooling also does not negatively in-
fluence the balance quality. That means risk of damage to the machine spindle due to changed balance qualities is generally
excluded.
Technical advices
Important operating instructions - please comply!
When shrink
gripping and shrink releasing tools,
always remove
the
COOLCAP
®
system caps
Never seal
COOLCAP
®
with additional sealants
such as PTFE thread seal tape or anything similar
Never use an open-end wrench, pipe wrench or adjustable screw-wrench
to tighten and loosen the caps.
The use of unsuitable tools voids the guaranty
Recommended tightening torques:
Tool diameter
(mm)
Wrench size
(mm)
Tightening torque
(Nm)
6
17
17
8
21
21
10
22
22
12
27
27
16
32
32
For long service life and process-reliable tightening and loosening of the caps, compliance with the specified tightening
torques is mandatory.
