pokolm - ARBOR AND ADAPTOR SYSTEM - page 102

102
latest items!  available as long as stock lasts  on request  stock item, subject to confirmation 
SK 40 DIN 69 871 AD
Drill chuck
Drill chuck
Catalogue no. Form/DIN AccessoriesFeatures d1 l3 A d3 d4 d 2 l2 l1
A
l 3
d3/d4
d2
d1
diam. 0.3 - 8 mm
BF 0,3-8 750 IC diam.
8
57 76.1 - 36 SK 40 DIN 69871
AD
- - A, C, D, E,
F, K  
diam. 0.5 - 13 mm
BF 0,5-13 750 IC diam.
13
97 116.1 - 50 SK 40 DIN 69871
AD
- - B, C, D, G,
H, L  
diam. 2.5 - 16 mm
BF 2,5-16 750 IC diam.
16
82 101.1 - 57 SK 40 DIN 69871
AD
- - B, C, D, I,
J, L  
Accessories
INBUS 4T
INBUS 4T
A > Page138
INBUS 6T
INBUS 6T
B > Page138
KBSK40-69872A
retention knob with
through hole
C > Page139
KBSK40-69872B
retention knob without
through hole
D > Page139
BF08DS04
seal gasket 08DS04
E > Page 140
BF08DS08
seal gasket 08DS08
F > Page140
BF13DS06
seal gasket 08DS08
G > Page140
BF13DS13
seal gasket13DS13
H > Page140
BF16DS06
seal gasket16DS06
I > Page140
BF16DS16
seal gasket 16DS16
J > Page140
BF08MW
hexagon key 08MW
K > Page140
BF13MW
hexagon key 13MW
L > Page140
• Steep taper shanks DIN 69871 AD, maximum precision
• approved for up to max. 7,000 rpm
• We can supply higher balance quality according to the balance classes on request
• with internal coolant supply and bore hole for the coolant supply tube
• independent of rotating direction
• extremely short and slim design
Scope of delivery includes small and large seal ring
Steep taper shanks SK / BT
