97
SK 40 DIN 69 871 AD
for shrinking | CoolCap®
• Steep taper shanks DIN 69871 AD, maximum precision
• balanced to G 6.3 gmm at 18,000 rpm
• ring shaped cooling jet for ideal cooling performance and chip flushing
for shrinking |
CoolCap®
Catalogue no.
Form/DIN
Accessories
Features
d
1
l
3
A d
3
d
4
d
2
l
2
l
1
d
3
d
2
l
3
d
1
d
4
A
for diam. 6
50 06 750 SR1 diam.
6
50 69.1 16.5 24.4 SK 40 DIN 69871
AD
-
-
A, B, G,
L, M
100 06 750 SR1 diam.
6
100 119.1 16.5 32.3 SK 40 DIN 69871
AD
-
-
A, B, G,
L, M
for diam. 8
50 08 750 SR1 diam.
8
50 69.1 20.5 28.4 SK 40 DIN 69871
AD
-
-
A, C, H,
L, M
100 08 750 SR1 diam.
8
100 119.1 20.5 36.3 SK 40 DIN 69871
AD
-
-
A, C, H,
L, M
for diam. 10
50 10 750 SR1 diam.
10
50 69.1 22.5 30.4 SK 40 DIN 69871
AD
-
-
A, D, I,
L, M
100 10 750 SR1 diam.
10
100 119.1 22.5 38.3 SK 40 DIN 69871
AD
-
-
A, D, I,
L, M
for diam. 12
60 12 750 SR1 diam.
12
60 79.1 26.5 36 SK 40 DIN 69871
AD
-
-
A, E, J,
L, M
100 12 750 SR1 diam.
12
100 119.1 26.5 42.3 SK 40 DIN 69871
AD
-
-
A, E, J,
L, M
Accessories
KBSK40-69872A
retention knob with
through hole
A > Page
SR1 S06 SW17
COOLCAP®-Screw-On
Cap for shrinking Ø 6
B > Page
SR1 S08 SW21
COOLCAP®-Screw-On
Cap for shrinking Ø 8
C > Page
SR1 S10 SW22
COOLCAP®-Screw-On
Cap for shrinking Ø 10
D > Page
SR1 S12 SW27
COOLCAP®-Screw-
On Cap for shrinking
Ø 12, > Page
SR1 S16 SW32
COOLCAP®-Screw-On
Cap for shrinking Ø 16
F > Page
SR1 A06 SW17
COOLCAP®-Screw-On
Cap for shrinking Ø 6
G > Page
SR1 A08 SW21
COOLCAP®-Screw-On
Cap for shrinking Ø 8
H > Page
SR1 A10 SW22
COOLCAP®-Screw-On
Cap for shrinking Ø 10
I > Page
SR1 A12 SW27
COOLCAP®-Screw-
On Cap for shrinking
Ø 12, J > Page
SR1 A16 SW32
COOLCAP®-Screw-On
Cap for shrinking Ø 16
K > Page
SR1 ZSW 001
COOLCAP®-applying
tool
L > Page
DMS 3/8 8-60 NM
torque wrench 3/8“
M > Page
1 / 2
▸
Important: the scope of delivery of each
COOLCAP
®
cooling arbor includes one cap each. When ordering, please
always state whether you want a cap for air/MMS or a cap for emulsion/cooling water. Additional caps can be orde-
red separately. Always tighten and loosen caps only with an application tool or a box wrench!
NEW
