93
SK 40 DIN 69 871 AD
for shrinking
• Steep taper shanks DIN 69871 AD, maximum precision
• balanced to G 6.3 gmm at 18,000 rpm
for shrinking
Catalogue no.
Form/DIN
Accessories
Features
d
1
l
3
A d
3
d
4
d
2
l
2
l
1
l
1
d
1
d
3
l
3
A
d
2
d
4
for diam. 3
50 03 750 S.01 diam.
3
50 69.1 9 15.6 SK 40 DIN 69871
AD
-
7.8 A, B
100 03 750 S.01 diam.
3
100 119.1 9 23.5 SK 40 DIN 69871
AD
-
7.8 A, B
for diam. 4
50 04 750 S.01 diam.
4
50 69.1 10.5 14.9 SK 40 DIN 69871
AD
-
7.8 A, B
75 04 750 S.01 diam.
4
75 94.1 10.5 17.54 SK 40 DIN 69871
AD
-
7.8 A, B
100 04 750 S.01 diam.
4
100 119.1 10.5 20.16 SK 40 DIN 69871
AD
-
7.8 A, B
for diam. 6
50 06 750 S diam.
6
50 69.1 12 16.4 SK 40 DIN 69871
AD
-
7.8 A, B
75 06 750 S diam.
6
75 94.1 12 19 SK 40 DIN 69871
AD
-
7.8 A, B
100 06 750 S diam.
6
100 119.1 12 21.7 SK 40 DIN 69871
AD
-
7.8 A, B
150 06 750 S diam.
6
150 169.1 12 27 SK 40 DIN 69871
AD
-
7.8 A, B
for diam. 8
50 08 750 S diam.
8
50 69.1 16 20.4 SK 40 DIN 69871
AD
-
7.8 A, B
75 08 750 S diam.
8
75 94.1 16 23 SK 40 DIN 69871
AD
-
7.8 A, B
100 08 750 S diam.
8
100 119.1 16 25.7 SK 40 DIN 69871
AD
-
7.8 A, B
for diam. 10
50 10 750 S diam.
10
50 69.1 20 24.4 SK 40 DIN 69871
AD
-
7.8 A, B
75 10 750 S diam.
10
75 94.1 20 27 SK 40 DIN 69871
AD
-
7.8 A, B
100 10 750 S diam.
10
100 119.1 20 29.7 SK 40 DIN 69871
AD
-
7.8 A, B
Accessories
KBSK40-69872A
retention knob with
through hole
A > Page
KBSK40-69872B
retention knob without
through hole
B > Page
1 / 2
▸
