60 22 Mxx 783
Ø 22
60
Ø 35
20
25
M 6 x 25
100 22 Mxx 783
Ø 22
100
Ø 35
20
25
M 6 x 25
60 27 Mxx 783
Ø 27
60
Ø 44,5
20
25
M 8 x 25
100 27 Mxx 783
Ø 27
100
Ø 44,5
20
25
M 8 x 25
50 22 782
Ø 22
50
Ø 35
20
25
M 6 x 55
100 22 782
Ø 22
100
Ø 35
20
25
M 6 x 55
50 27 782
Ø 27
50
Ø 44,5
20
25
M 8 x 55
100 27 782
Ø 27
100
Ø 44,5
20
25
M 8 x 55
OUR POKOLM BAG OF TRICKS
Shell-type Extensions
Reduction adapters - shell type to thread connections
You have to machine an extensive deep component? The requested arbor-extension
is not available as a standard item? The production of customized arbors is too ex-
pensive? There is no time left for any special action?
SPECIAL SITUATIONS REQUIRE SPECIAL SOLUTIONS.
Our latest shell-type extensions and the thread-connections/shell-type combi adapters al-
low to achieve a possibility of assembling tool beyond our standard range.
1. an existing standard arbor has to be equipped with supplement bore holes according
to our adjoining sketch.
2. screw on your selected adapter.
3. start your job.
THIS RESULTS IN EXTENSIONS BETWEEN 50 AND 100 MM
Extension - top view
Extension - side view
Tool
Diameter of
Spigot
Extensions
length
A
B
C
Screws*
Catalogue No.
Thread connection –
Shell-type Combi Adapters
Thread connection –
Shell-type Combi Adapters
Thread connection –
Shell-type Combi Adapters
Thread connection –
Shell-type Combi Adapters
Shell-type Extensions
Shell-type Extensions
Shell-type Extensions
Shell-type Extensions
M x length
*for fixing an adapter, you need 4 screws each, included in extent of supply.
You are going to find all available sizes and designs in the catalogue about arbors and adapters.
