CUTTERS FOR ROUND INSERTS - K0-90°
r5 - diam. 20 - 42 mm, neutral - 0° axial rake angle
The all-rounder:
Tools are applicable for a wide range of milling operations.
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
d r
l
3
l
2
l
1
d
2
d
3
z
DuoPlug®
l
2
d
1
d
l
3
d
3
d
2
20 200 SG 20 10 5 35 -
-
M 12 18.6 2 A, B, C, D, E
3 25 200 SG 25 10 5 35 2.8 -
M 16 23.5 3 A, B, C, D, E
Threaded shank end mill bodies
d
d
1
l
3
d
3
d
2
l
2
20 200 20 10 5 29 -
-
M 10 18 2 A, B, C, D, E
2 25 200 25 10 5 33 2.8 -
M 12 21 2 A, B, C, D, E
3 25 200 25 10 5 33 2.8 -
M 12 21 3 A, B, C, D, E
4 25 200 25 10 5 33 2.8 -
M 12 21 4 A, B, C, D, E
4 30 201 30 10 5 33 2.8 -
M 12 21 4 A, B, C, D, E
4 30 200 30 10 5 43 2.8 -
M 16 29 4 A, B, C, D, E
5 35 200 35 10 5 43 2.8 -
M 16 29 5 A, B, C, D, E
N 5 42 200 42 10 5 43 2.8 -
M 16 29 5 A, B, C, D, E
6 42 200 42 10 5 43 2.8 -
M 16 29 6 A, B, C, D, E
End mill bodies with plain shanks and flats
l
1
l
4
d
1
d
l
3
d
2
l
2
40 20 100 20 10 5 40 -
23 diam. 20 -
2 A, B, C, D, E
60 20 100 20 10 5 60 -
23 diam. 20 -
2 A, B, C, D, E
80 20 100 20 10 5 80 -
23 diam. 25 -
2 A, B, C, D, E
100 20 100 20 10 5 100 -
23 diam. 25 -
2 A, B, C, D, E
120 20 100 20 10 5 120 -
23 diam. 25 -
2 A, B, C, D, E
