CUTTERS FOR ROUND INSERTS - K0-90°
r5 - diam. 20 - 35 mm, CBN, neutral - 0° axial rake angle
Specially designed for high-speed super-finish milling of hardened steel.
Indexable inserts
Catalogue no.
DIN Specification
Carbide Grade
Coating
d
s
r
M
s
11°
d
02 10 092 RPHN 1003 M0
CBN for steel
uncoated
10
3.18
5
02 10 093 RPHN 1003 M0
CBN for cast iron
uncoated
10
3.18
5
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
d r
l
3
l
2
l
1
d
2
d
3
z
DuoPlug®
l
2
d
1
d
d
3
l
3
d
2
2 20 294 SG 20 10 5 39.5 -
-
M 12 18.5 2 A, B, C, D, E
3 25 294 SG 25 10 5 41.5 2.5 -
M 16 23.5 3 A, B, C, D, E
Threaded shank end mill bodies
d
d
2
d
3
l
3
d
1
l
2
20 294 20 10 5 28.5 -
-
M 10 18 2 A, B, C, D, E
25 294 25 10 5 32.5 2.5 -
M 12 21 3 A, B, C, D, E
30 294 30 10 5 32.5 2.5 -
M 12 21 4 A, B, C, D, E
35 294 35 10 5 42.5 2.5 -
M 16 29 4 A, B, C, D, E
Accessories
10 500
Torx-screwdriver
A > Page
TV 2-8
Screwdriver torque
Vario®-S with window
scale, B > Page
T10 500
Torx interchangeable bit
for Torque Vario®
C > Page
T10 502
Torx MagicSpring
compatible bit f. Torque
Vario®, D > Page
10 514
clamping finger for CBN
E > Page
