pokolm - Milling Cutter Bodies - page 86

86
 latest items! available as long as stock lasts  on request  stock item, subject to confirmation 
Milling cutter bodies
Catalogue no. AccessoriesFeatures d 1 d r l3 l2 l1 d2 d3 z
Shell type milling cutter bodies
d
l 2
l 3
d3
d 1
d2
6 42 310 42 10 5 43 2.8 - diam. 16 35 6 A, B, C, D, E    
Accessories
35 500
Torx screw
A > Page195
15 500
Torx-screwdriver
B > Page196
TV 2-8
Screwdriver torque
Vario®-S with window
scale, C > Page197
T15 500
Torx interchangeable bit
for Torque Vario®
D > Page197
T15 502
Torx MagicSpring compati-
ble bit f. Torque Vario®
E > Page198
Indexable inserts
Catalogue no. DIN Specification Carbide Grade Coating d s r M
s
15°
d
02 10 835 RDHX 1003 M0T HSC 05 PVTi 10 3.18 5 M 3.5
02 10 837 RDMX 1003 M0T HSC 05 PVFN 10 3.18 5 M 3.5
02 10 840 RDHX 1003 M0T P40 PVTi 10 3.18 5 M 3.5
02 10 842 RDEX 1003 M0T P40 PVSR 10 3.18 5 M 3.5
02 10 8042 RDEX 1003 M0T P40 PCSR 10 3.18 5 M 3.5
02 10 844 RDHX 1003 M0T P40 PVML 10 3.18 5 M 3.5
02 10 846 RDMX 1003 MOSN P40 PVGO 10 3.18 5 M 3.5
02 10 850 RDHX 1003 M0T P25 PVTi 10 3.18 5 M 3.5
02 10 852 RDEX 1003 M0T P25 PVSR 10 3.18 5 M 3.5
02 10 860 RDHX 1003 M0T K10 PVTi 10 3.18 5 M 3.5
02 10 892 RDHX 1003 M0T CBN for steel uncoated 10 3.18 5 M 3.5
02 10 893 RDHX 1003 M0T CBN for cast iron uncoated 10 3.18 5 M 3.5
s
15°
d
02 10 831P RDHX 1003 M0T K10 polished 10 3.18 5 M 3.5
02 10 848 RDMX 1003 M0T P40 PVGO 10 3.18 5 M 3.5
02 10 880 RDHX 1003 M0T K10 PVTi 10 3.18 5 M 3.5
02 10 880 D RDHX 1003 M0T K10 PVDiaN 10 3.18 5 M 3.5
02 10 896 RDMT 1003 M0EN M40 PVST 10 3.18 5 M 3.5
02 10 897 RDPX 1003 M0T P25 PVGO 10 3.18 5 M 3.5
02 10 8099 RDMT 1003 M0EN M35 PCTC 10 3.18 5 M 3.5
 Cutters for round inserts - k0-90°  Copy cutters
