97
major application
minor application
roughing
pre-finishing
finishing
CUTTERS FOR ROUND INSERTS - K0-90°
r6 - diam. 42 - 80 mm, 7° positive rake angle, with shims
• increased reliability against fractures during machining
• optimum protection of milling cutter body by shim
• in case of insert fracture, shims, screws and threaded bushes can be replaced separa-
tely, it is not necessary to buy a new body
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
d r
l
3
l
2
l
1
d
2
d
3
z
Shell type milling cutter bodies
l
2
d
1
d
3
l
3
d
2
d
42 310/7 HL 42 12 6 42 3.5 -
diam. 16 35 4
A,B,C,D,E,F,G,H, I
52 310/7 HL 52 12 6 52.5 3.5 -
diam. 22 40 5
A,B,C,D,E,F,G,H, I
66 310/7 HL 66 12 6 52.5 3.5 -
diam. 27 48 6
A,B,C,D,E,F,G,H, I
80 310/7 HL 80 12 6 52.5 3.5 -
diam. 27 60 7
A,B,C,D,E,F,G,H, I
Accessories
35 500 L
Torx screw
A > Page
35 510
locking screw
B > Page
35 500 I
threaded and tapped
bush
C > Page
09 511
Shim for RDHX 12T3
D > Page
15 500
Torx-screwdriver
E > Page
INBUS 3,5 W
Allen key 3,5
F > Page
TV 2-8
Screwdriver torque Va-
rio®-S with window scale
G > Page
T15 500
Torx interchangeable
bit for Torque Vario®
H > Page
T15 502
Torx MagicSpring compa-
tible bit f. Torque Vario®
I > Page
