major application
minor application
roughing
pre-finishing
finishing
CUTTERS FOR ROUND INSERTS - K0-90°
r6 - diam. 24 - 80 mm, neutral or 7° positive rake angle
The allrounder:
• for high-speed-machining centres
• 7° only for roughing-operations
• 0° for roughing- and finishing-operations
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
d r
l
3
l
2
l
1
d
2
d
3
z
Threaded shank end mill bodies | 0° axial rake angle
d
d
1
l
3
d
3
d
2
24 200 24 12 6 33 -
-
M 12 21 2 A, B, C, D, E, F
35 200 35 12 6 43 3 -
M 16 29 3 A, B, C, D, E, F
4 35 200 35 12 6 43 3 -
M 16 29 4 A, C, D, E, F
42 200 42 12 6 43 3 -
M 16 29 4 A, B, D, E, F
5 42 200 42 12 6 43 3 -
M 16 29 5 A, C, D, E, F
Shell tp. mill. cutt. bodies | 0° axial rake angle
l
2
d
1
d
l
3
d
3
d
2
4 42 310 42 12 6 43 3 -
diam. 16 35 4 A, B, C, D, E, F
5 42 310 42 12 6 43 3 -
diam. 16 35 5 A, C, D, E, F
52 310 52 12 6 53 3.5 -
diam. 22 40 5 A, B, C, D, E, F
Thr. sh. end mill bodies | 7° pos. rake angle
d
3
d
2
d
l
2
l
3
d
1
3 35 200/7 35 12 6 42.5 3 -
M 16 29 3 A, B, C, D, E, F
4 35 200/7 35 12 6 42.5 3 -
M 16 29 4 A, C, D, E, F
