CUTTERS FOR ROUND INSERTS - K0-90°
r8 - diam. 52 - 100 mm, 7° positive rake angle, with shims
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
d r
l
3
l
2
l
1
d
2
d
3
z
Shell type milling cutter bodies
l
2
d
1
d
3
l
3
d
2
d
52 300/7 HL 52 16 8 53 4.1 -
diam. 22 40 4
A,B,C,D,E,F,G,H, I, J
66 300/7 HL 66 16 8 53 4.1 -
diam. 27 48 5
A,B,C,D,E,F,G,H, I, J
80 300/7 HL 80 16 8 53 4.1 -
diam. 27 60 6
A,B,C,D,E,F,G,H, I, J
100 300/7 HL 100 16 8 53 4.1 -
diam. 32 70 7 A, B, C, D, E, F,
G, H, I, J
Accessories
45 500
Torx screw
A > Page
45 500 L
Torx screw
B > Page
45 500 I
threaded and tapped
bush
C > Page
10 510
locking washer
D > Page
10 511
Shim for RDHX 1604
E > Page
20 500
Torx-screwdriver
F > Page
INBUS 4,5 W
Allen Key 4,5
G > Page
TV 2-8
Screwdriver torque
Vario®-S with window
scale, H > Page
T20 500
Torx interchangeable bit
for Torque Vario®
I > Page
T20 502
Torx MagicSpring
compatible bit f. Torque
Vario®, J > Page
• increased reliability against fractures during machining
• optimum protection of milling cutter body by shim
• in case of insert fracture, shims, screws and threaded bushes can be replaced separa-
tely, it is not necessary to buy a new body
Cutters for round inserts - k0-90° Copy cutters
