11
major application
minor application
roughing
pre-finishing
finishing
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
l
r
l
3
l
2
l
1
d
2
d
3
z
Shell type milling cutter bodies
d
1
l
2
l
3
l
d
3
r
d
2
5 42 367 42 10 0.8-2 43 2.5 -
diam. 16 35 5 B, C, D,
E, F
5 42 367 R+ 42 10 3|4 43 2.5 -
diam. 16 35 5 B, C, D,
E, F
6 52 367 52 10 0.8-2 53 2.5 -
diam. 22 40 6 B, C, D,
E, F
6 52 367 R+ 52 10 3|4 53 2.5 -
diam. 22 40 6 B, C, D,
E, F
Accessories
25 505 KP
Torx screw
A > Page 23
25 505 P
Torx screw for Slotworx M
B > Page 23
08 500 P
Torx-screwdriver
(Torx-Plus)
C > Page 23
TV 08-2
Screwdriver torque
Vario®-S with window
scale, D > Page 23
T8 500 P
Torx interchangeable bit
for Torque Vario®
E > Page 23
T8 502 P, Torx Ma-
gicSpring compatible
bit f. Torque Vario®,
F > Page 23
Indexable inserts
Catalogue no.
DIN Specification
Carbide Grade
Coating
l
s
r
M
s
l
r
04 67 837 R08 XDMT 10T308 ER
HSC 05
PVFN
10
3.58
0.8
M 2.5
04 67 848 R08 XDMT 10T308 ER
P40
PVGO
10
3.58
0.8
M 2.5
04 67 820 XDHT 10T310 ER
K10
polished
10
3.58
1
M 2.5
04 67 837 XDMT 10T310 ER
HSC 05
PVFN
10
3.58
1
M 2.5
04 67 844 XDHT 10T310 ER
P40
PVGO
10
3.58
1
M 2.5
04 67 848 XDMT 10T310 ER
P40
PVGO
10
3.58
1
M 2.5
04 67 860 XDHT 10T310 ER
K10
PVTi
10
3.58
1
M 2.5
04 67 860 D XDHT 10T310 ER
K10
PVDiaN
10
3.58
1
M 2.5
04 67 894 XDHT 10T310 ER
PCD
uncoated
10
3.58
1
M 2.5
04 67 896 XDMT 10T310 ER
M40
PVST
10
3.58
1
M 2.5
04 67 820 R20 XDHT 10T320 FR
K10
polished
10
3.58
2
M 2.5
04 67 896 R20 XDMT 10T320 ER
M40
PVST
10
3.58
2
M 2.5
04 67 820 R30 XDHT 10T330 FR
K10
polished
10
3.58
3
M 2.5
04 67 896 R30 XDMT 10T330 ER
M40
PVST
10
3.58
3
M 2.5
04 67 820 R40 XDHT 10T340 FR
K10
polished
10
3.58
4
M 2.5
04 67 896 R40 XDMT 10T340 ER
M40
PVST
10
3.58
4
M 2.5
