79
HSK 100 FORM A
Drill chuck
• Hollow taper shank arbor CNC precision drill chuck according to DIN69893 form E,
maximum precision
• approved for up to max. 7,000 rpm
• We can supply higher balance quality according to the balance classes upon request
• with internal coolant supply and bore hole for the coolant supply tube
• independent of rotating direction
• extremely short and slim design
Scope of delivery includes small and large seal ring
Drill chuck
Catalogue no.
Form/DIN
Accessories
Features
d
1
l
3
A d
3
d
4
d
2
l
2
l
1
A
l
3
d
2
d
3
/d
4
d
1
diam. 0.5 - 13 mm
BF 0,5-13 A100 IC diam.
13
89 118 -
50 HSK
100
form A -
-
A, B, C, D,
E, H
diam. 2.5 - 16 mm
BF 2,5-16 A100 IC diam.
16
83 112 -
57 HSK
100
form A -
-
A, B, C, F,
G, H
Accessories
INBUS 6T
INBUS 6T
A > Page
KMR-100A
coolant supply tube for
HSK-tooling
B > Page
SCHLUESSELHSK100
spanner for coolant
tube
C > Page
BF13DS06
seal gasket 08DS08
D > Page
BF13DS13
seal gasket13DS13
E > Page
BF16DS06
seal gasket16DS06
F > Page
BF16DS16
seal gasket 16DS16
G > Page
BF13MW
hexagon key 13MW
H > Page
