HSK 100 FORM A
for shell-type milling
• Hollow taper shank arbors according to DIN69893 form A, maximum precision
• fine balanced to G 6.3 gmm at 12,000 rpm
• with internal coolant supply and bore hole for the coolant supply tube
for shell-type milling
Catalogue no.
Form/DIN
Accessories
Features
d
1
l
3
A d
3
d
4
d
2
l
2
l
1
A
l
1
d
4
d
3
l
3
d
2
d
1
bore diam. 22
50 22 A100 diam.
22
50 79 40 40 HSK
100
form A -
-
A, C, G,
J, K
75 22 A100 diam.
22
75 104 48 48 HSK
100
form A -
-
A, C, G,
J, K
100 22 A100 diam.
22
100 129 48 50 HSK
100
form A -
7.8 A, C, G,
J, K
150 22 A100 diam.
22
150 179 48 50 HSK
100
form A -
7.8 A, C, G,
J, K
200 22 A100 diam.
22
200 229 48 50 HSK
100
form A -
7.8 A, C, G,
J, K
bore diam. 27
50 27 A100 diam.
27
50 79 62 62 HSK
100
form A -
-
B, D, H,
J, K
75 27 A100 diam.
27
75 104 62 62 HSK
100
form A -
-
B, D, H,
J, K
100 27 A100 diam.
27
100 129 62 71 HSK
100
form A -
7.8 B, D, H,
J, K
150 27 A100 diam.
27
150 179 62 80 HSK
100
form A -
7.8 B, D, H,
J, K
200 27 A100 diam.
27
200 229 62 80 HSK
100
form A -
7.8 B, D, H,
J, K
Accessories
M4X10
screw for drive block
10 x 8
A > Page
M5X16
screw for drive blocks
12 x 12 and 14 x 14
B > Page
M10X35
screw M10X35 DIN
912 | 10.9
C > Page
M12X35
screw M12X35 | 10.9
D > Page
M16X26
screw M16X26 DIN
6367
E > Page
M20X30
screw M20X30 DIN
6367
F > Page
NUTEN10X8
drive block 10 x 8
G > Page
NUTEN12X12/2
drive block 12 x 12
H > Page
NUTEN14X14
drive block 14 x 14
I > Page
KMR-100A
coolant supply tube
for HSK-tooling
J > Page
SCHLUESSELHSK100
spanner for coolant tube
K > Page
