HSK 100 FORM A
for shrinking
• Hollow taper shank arbors according to DIN69893 form A, maximum precision
• fine balanced to G 6.3 gmm at 12,000 rpm
• with internal coolant supply and bore hole for the coolant supply tube
for shrinking
Catalogue no.
Form/DIN
Accessories
Features
d
1
l
3
A d
3
d
4
d
2
l
2
l
1
A
l
1
d
3
l
3
d
2
d
1
d
4
for diam. 6
100 06 A100 S diam.
6
100 129 12 22 HSK
100
form A -
7.8 A, B
150 06 A100 S diam.
6
150 179 12 26.9 HSK
100
form A -
7.8 A, B
for diam. 8
100 08 A100 S diam.
8
100 129 16 25.7 HSK
100
form A -
7.8 A, B
150 08 A100 S diam.
8
150 179 16 30.9 HSK
100
form A -
7.8 A, B
for diam. 10
100 10 A100 S diam.
10
100 129 20 29.7 HSK
100
form A -
7.8 A, B
150 10 A100 S diam.
10
150 179 20 35 HSK
100
form A -
7.8 A, B
for diam. 12
100 12 A100 S diam.
12
100 129 24 33.7 HSK
100
form A -
7.8 A, B
150 12 A100 S diam.
12
150 179 24 39 HSK
100
form A -
7.8 A, B
for diam. 16
60 16 A100 S diam.
16
60 89 32 37.5 HSK
100
form A -
7.8 A, B
100 16 A100 S diam.
16
100 129 32 41.7 HSK
100
form A -
7.8 A, B
150 16 A100 S diam.
16
150 179 32 46.9 HSK
100
form A -
7.8 A, B
for diam. 20
60 20 A100 S diam.
20
60 89 40 40 HSK
100
form A -
-
A, B
for diam. 25
60 25 A100 S diam.
25
60 89 46 46 HSK
100
form A -
7.8 A, B
Accessories
KMR-100A
coolant supply tube for
HSK-tooling
A > Page
SCHLUESSELHSK100
spanner for coolant tube
B > Page
