HSK 100 FORM A
for Weldonshanks | CoolCap®
for Weldonshanks |
CoolCap®
Catalogue no.
Form/DIN
Accessories
Features
d
1
l
3
A d
3
d
4
d
2
l
2
l
1
d
2
A
l
3
d
3
d
1
d
4
for diam. 10
100 10 A100 SR1 W diam.
10
100 129 22.5 30.4 HSK
100
form A -
-
A, D, E, F,
I, L, M
for diam. 12
100 12 A100 SR1 W diam.
12
100 129 26.5 36 HSK
100
form A -
-
B, D, E, G,
J, L, M
for diam. 16
100 16 A100 SR1 W diam.
16
100 129 31.5 41 HSK
100
form A -
-
C, D, E, H,
K, L, M
Accessories
M10X10
screw for reduction
sleeve
A > Page
M12X10
screw
B > Page
M14X12
screw
C > Page
KMR-100A
coolant supply tube for
HSK-tooling
D > Page
SCHLUESSELHSK100
spanner for coolant
tube
E > Page
SR1 S10 SW22
COOLCAP®-Screw-On
Cap for shrinking Ø 10
F > Page
SR1 S12 SW27
COOLCAP®-Screw-On
Cap for shrinking Ø 12
G > Page
SR1 S16 SW32
COOLCAP®-Screw-On
Cap for shrinking Ø 16
H > Page
SR1 A10 SW22
COOLCAP®-Screw-On
Cap for shrinking Ø 10
I > Page
SR1 A12 SW27
COOLCAP®-Screw-
On Cap for shrinking
Ø 12, J > Page
SR1 A16 SW32
COOLCAP®-Screw-On
Cap for shrinking Ø 16
K > Page
SR1 ZSW 001
COOLCAP®-applying
tool
L > Page
DMS 3/8 8-60 NM
torque wrench 3/8“
M > Page
• Hollow taper shank arbors according to DIN69893 form A, maximum precision
• fine balanced to G 6.3 gmm at 12,000 rpm
• ring shaped cooling jet for ideal cooling performance and chip flushing
Important: the scope of delivery of each
COOLCAP
®
cooling arbor includes one cap each. When ordering, please
always state whether you want a cap for air/MMS or a cap for emulsion/cooling water. Additional caps can be orde-
red separately. Always tighten and loosen caps only with an application tool or a box wrench!
Hollow taper shanks HSK
