78
latest items!
available as long as stock lasts
on request
stock item, subject to confirmation
for shell-type milling
Catalogue no.
Form/DIN
Accessories
Features
d
1
l
3
A d
3
d
4
d
2
l
2
l
1
A
l
1
d
4
d
3
l
3
d
2
d
1
bore diam. 32
50 32 A100 diam.
32
50 79 85 85 HSK
100
form A -
-
B, E, I, J, K
100 32 A100 diam.
32
100 129 85 85 HSK
100
form A -
-
B, E, I, J, K
150 32 A100 diam.
32
150 179 85 85 HSK
100
form A -
-
B, E, I, J, K
bore diam. 40
50 40 A100 diam.
40
50 79 100 88 HSK
100
form A -
-
B, F, I, J, K
Accessories
M4X10
screw for drive block
10 x 8
A > Page
M5X16
screw for drive blocks
12 x 12 and 14 x 14
B > Page
M10X35
screw M10X35 DIN
912 | 10.9
C > Page
M12X35
screw M12X35 | 10.9
D > Page
M16X26
screw M16X26 DIN
6367
E > Page
M20X30
screw M20X30 DIN
6367
F > Page
NUTEN10X8
drive block 10 x 8
G > Page
NUTEN12X12/2
drive block 12 x 12
H > Page
NUTEN14X14
drive block 14 x 14
I > Page
KMR-100A
coolant supply tube
for HSK-tooling
J > Page
SCHLUESSELHSK100
spanner for coolant tube
K > Page
• Hollow taper shank arbors according to DIN69893 form A, maximum precision
• fine balanced to G 6.3 gmm at 12,000 rpm
• with internal coolant supply and bore hole for the coolant supply tube
HSK 100 FORM A
for shell-type milling
◂
2 / 2
Hollow taper shanks HSK
