109
major application
minor application
roughing
pre-finishing
finishing
CUTTERS FOR ROUND INSERTS - K0-90°
r8 - diam. 32 - 160 mm, neutral, 7° positive
The first choice when using SK 50 machines for medium and heavy milling. Tools with a
7° rake angle are characterized by its low energy consumption.
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
d
r
l
3
l
2
l
1
d
2
d
3
z
Threaded shank end mill bodies
d
d
1
l
3
d
3
d
2
l
2
32 200 32 16 8 43.5 -
-
M 16 29 2 A, C, D, E, F
35 201 35 16 8 43.5 4 -
M 16 29 3 A, C, D, E, F
Shell tp. mill. cutt. bodies | 0° axial rake angle
l
2
d
1
d
l
3
d
3
d
2
52 300 52 16 8 53.5 4.7 -
diam. 22 40 4
A, B, C, D, E, F
66 300 66 16 8 53.5 5.1 -
diam. 27 48 5
A, B, C, D, E, F
80 300 80 16 8 53.5 5.8 -
diam. 27 60 6
A, B, C, D, E, F
100 300 100 16 8 53.5 5.8 -
diam. 32 70 7
A, B, C, D, E, F
Shell tp. mill. cutt. bodies | 7° pos. rake angle
l
2
d
3
d
2
l
3
d
d
1
5 52 300/7 52 16 8 53 4.1 -
diam. 22 40 5
A, C, D, E, F
66 300/7 66 16 8 53 4.6 -
diam. 27 48 5
A, B, C, D, E, F
6 66 300/7 66 16 8 53 5.1 -
diam. 27 48 6
A, C, D, E, F
80 300/7 80 16 8 53 5.1 -
diam. 27 60 6
A, B, C, D, E, F
100 300/7 100 16 8 53 5.1 -
diam. 32 70 7
A, B, C, D, E, F
125 300/7 125 16 8 53 5.1 -
diam. 40 90 8
A, B, C, D, E, F
160 300/7 160 16 8 53 5.1 -
diam. 40 120 9
A, B, C, D, E, F
Accessories
45 500
Torx screw
A > Page
10 510
locking washer
B > Page
20 500
Torx-screwdriver
C > Page
TV 2-8
Screwdriver torque
Vario®-S with window
scale, D > Page
T20 500
Torx interchangeable bit
for Torque Vario®
E > Page
T20 502, Torx Magic-
Spring compatible bit
f. Torque Vario®
F > Page
