DOUBLETRIGA
Size M
Indexable inserts
Catalogue no.
DIN Specification
Carbide Grade
Coating
d
s
r
M
05 90 854 WNHX 125010 ER
P25
PVGO
12
5
1
M 3,5
s
r
d
05 90 850 R30 WNHX 125030 SR
P25
PVSR
12
5
3
M 3,5
05 90 860 R30 WNHX 125030 SR
K10
PVTi
12
5
3
M 3,5
05 90 890 R30 WNHX 125030 SR
M40
PVST
12
5
3
M 3,5
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
d r
l
3
l
2
l
1
d
2
d
3
z
Threaded shank end mill bodies
l
3
l
2
d
1
d
3
d
2
r
d
2 32 290 32 12 1|3 42.5 1 -
M 16 29 2 A, C, D, E, F
3 35 290 35 12 1|3 42.5 1 -
M 16 29 3 A, C, D, E, F
Shell-type milling cutter bodies
l
2
d
1
d
l
3
d
3
r
d
2
4 42 390 42 12 1|3 40 1 -
diam. 16 35 4 A, B, C, D, E, F
5 52 390 52 12 1|3 50 1 -
diam. 22 48 5 A, C, D, E, F
6 66 390 66 12 1|3 50 1 -
diam. 27 48 6 A, C, D, E, F
8 80 390 80 12 1|3 50 1 -
diam. 27 60 8 A, C, D, E, F
Accessories
35 505 P
Torx screw
A > Page
GWSTPS8ISK
hexagon socket set
screw
B > Page
10 500 P
Torx-screwdriver
(Torx-Plus)
C > Page
TV 1-5
Screwdriver torque
Vario®-S with window
scale, D > Page
T10 500 P
Torx interchangeable bit
for Torque Vario®
E > Page
T10 502 P, Torx Ma-
gicSpring compatible
bit f. Torque Vario®
F > Page
• six cutting edges per insert for maximum efficiency
• high cutting rate while maintaining an excellent finish quality
• all tools feature an internal coolant supply
• high feed rates of up to f
z
1.5 mm are feasible
• secure positioning and fixation with anti-twist protection of the inserts
Doubletriga Face milling / Square shoulder face milling / Copy cutters
