major application
minor application
roughing
pre-finishing
finishing
Machining types
Connection types
Properties
Cutting materials
XDHW | XDHT
RHOMBIC CUTTERS - SIZES 06 / 10
Universal tool for finishing and contour cutting with small radii
uu
Particularly smooth tool running
in corners and pockets
uu
Low power consumption
uu
Approach angle Kappa
Size 06: 93°, Size 10: 95°
06 - diam. 16 - 42 mm | r1 126
06 - diam. 16 - 35 mm | r2 129
10 - diam. 25 - 80 mm | r1 131
Size
Page
Carbide grade
Coating
HSC 05 PVTi
PKD
K10 PVTi
CBN for steel
K10 polished
K10 PVDiaN
ISO standard
feed per tooth | d.o.c.
f
z
(mm)
a
p
(mm)
l (mm)
s (mm)
r (mm)
length
thickness
radius
