147
major application
minor application
roughing
pre-finishing
finishing
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
d r
l
3
l
2
l
1
d
2
d
3
z
Plain shank end mill bodies
r
l
3
l
1
d
2
d
1
50 08 114 8 8 3|4 50 -
20 diam. 12 -
2 A, E, K, L, P
30 10 114 10 10 4|5 30 -
20 diam. 12 -
2 B, F, I, M, Q
50 12 114 12 12 5|6 50 -
50 diam. 12 -
2 C, G, J, N, R
60 16 114 16 16 7|8 60 -
26 diam. 20 -
2 D, H, J, O, S
80 20 114 20 20 8|10 80 -
80 diam. 20 -
2 D, H, J, O, S
Accessories
30 522
locating screw
A > Page
35 520
locating screw
B > Page
40 520
locating screw
C > Page
50 520
locating screw
D > Page
08 500
Torx-screwdriver
E > Page
10 500
Torx-screwdriver
F > Page
15 500
Torx-screwdriver
G > Page
20 500
Torx-screwdriver
H > Page
TV 1-5
Screwdriver torque
Vario®-S with window
scale, I > Page
TV 2-8
Screwdriver torque
Vario®-S with window
scale, J > Page
TV 08-2
Screwdriver torque Va-
rio®-S with window scale
K > Page
T8 500
Torx interchangeable
bit for Torque Vario®
L > Page
T10 500
Torx interchangeable bit for
Torque Vario®
M > Page
T15 500
Torx interchangeable
bit for Torque Vario®
N > Page
T20 500
Torx interchangeable bit
for Torque Vario®
O > Page
T8 502
Torx MagicSpring
compatible bit f. Torque
Vario®, P > Page
T10 502
Torx MagicSpring compati-
ble bit f. Torque Vario®
Q > Page
T15 502, Torx Magic-
Spring compatible bit
f. Torque Vario®
R > Page
T20 502
Torx MagicSpring compati-
ble bit f. Torque Vario®
S > Page
