UNIWORX®
Ø 8 mm - Ø 20 mm
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
d r
l
3
l
2
l
1
d
2
d
3
z
DuoPlug®
r
l
3
d
3
d
1
d
2
10 214 SG 10 10 4|5 30.5 -
-
M 5 9.6 2 B, F, I, M, Q
12 214 SG 12 12 5|6 33.5 -
-
M 7 10.8 2 C, G, J, N, R
16 214 SG 16 16 7|8 40 -
-
M 10 15 2 D, H, J, O, S
20 214 SG 20 20 8|10 42.5 -
-
M 12 18.5 2 D, H, J, O, S
Threaded shank end mill bodies
r
l
1
l
3
d
3
d
2
d
1
08 214 M6 8 8 3|4 26 -
18.9 M 6 9.6 2 A, E, K, L, P
08 214 8 8 3|4 26 -
18.9 M 5 9.6 2 A, E, K, L, P
10 214 M6 10 10 4|5 24.5 -
-
M 6 9.75 2 B, F, I, M, Q
12 214 M6 12 12 5|6 28.5 -
-
M 6 11.5 2 C, G, J, N, R
16 214 16 16 7|8 36.5 -
-
M 8 13.8 2 D, H, J, O, S
20 214 20 20 8|10 37 -
-
M 10 18 2 D, H, J, O, S
Our ball nose and bull end combi end mills provide maximum precision because of
both the V-shaped insert seat and because the insert was ground in only one setup. The
helix-shaped rake angle allows very easy cutting and extremely smooth operation.
Only for finishing and pre-finishing operations.
Uniworx® Ball end bull end mill cutters
