140
latest items!
available as long as stock lasts
on request
stock item, subject to confirmation
VCGT - K90°
diam. 32 - 80 mm | r3
Indexable inserts
Catalogue no.
DIN Specification
Carbide Grade
Coating
l
s
r
M
s
l
r
05 22 820 VCGT 220530 FN
K10
polished
16
5.56
3
M 4.5
05 22 860 VCGT 220530 FN
K10
PVTi
16
5.56
3
M 4.5
05 22 860 D VCGT 220530 FN
K10
PVDiaN
16
5.56
3
M 4.5
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
l
r
l
3
l
2
l
1
d
2
d
3
z
Threaded shank end mill bodies
d
1
d
3
d
2
r
l
2
l
l
3
32 260-90 32 16 3 48 9.5 -
M 16 29 2 A, C, D, E, F
42 260-90 42 16 3 48 9.5 -
M 16 29 3 A, C, D, E, F
Shell type milling cutter bodies
d
1
d
3
d
2
r
l
l
3
l
2
42 360-90 42 16 3 57 9.5 -
diam. 16 35 3 A, B, C, D, E, F
52 360-90 52 16 3 57 9.5 -
diam. 22 40 3 A, C, D, E, F
66 360-90 66 16 3 57 9.5 -
diam. 27 48 4 A, C, D, E, F
80 360-90 80 16 3 57 9.5 -
diam. 27 60 5 A, C, D, E, F
Accessories
45 500
Torx screw
A > Page
GWSTPS8ISK
hexagon socket set
screw
B > Page
20 500
Torx-screwdriver
C > Page
TV 2-8
Screwdriver torque
Vario®-S with window
scale, D > Page
T20 500
Torx interchangeable bit
for Torque Vario®
E > Page
T20 502, Torx Magic-
Spring compatible bit
f. Torque Vario®
F > Page
These milling cutters are especially suitable for milling aluminium, copper, plastics and
graphite. It allows very easy cutting and very high cutting speeds and feed rates.
Only for roughing and pre-finishing operations!
VCGT - k92° Cutters for non-ferrous materials
