155
P M
K
N S
H
0.1
0.1
10
2.5
5
0.12
0.1
12
3.0
6
0.16
0.1
16
4.0
8
0.2
0.1
20
5.0
10
major application
minor application
roughing
pre-finishing
finishing
Machining types
Connection types
Properties
Cutting materials
Sizes
Page
uu
Double economic efficiency due to reversible
inserts
uu
Thanks to special insert geometry ideally
suitable for finishing and rough finishing
operations on modern HSC 5 axis machines
uu
Optimum utilisation at approach angle
of spindle
diam. 10 mm - 20 mm 156
CUTTERS FOR INSERTS
WITH 4 CUTTING EDGES
For finishing and rough finishing operations on HSC 5 axis machines
Carbide grade
Coating
K 05 | PVTi
ISO standard
feed per tooth | d.o.c.
a
p
(mm)
f
z
(mm)
diam.
d (mm)
thickness
s (mm)
radius
r (mm)
