SLOTWORX® HP
Size S - HP
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
l
r
l
3
l
2
l
1
d
2
d
3
z
DuoPlug®
d
3
l
3
l
2
r
d
1
d
2
3 12 266 SG 12 6.2 2 28 0.7 -
M 7 10.8 3 A, B, C, D, E, F
4 16 266 SG 16 6.2 2 31 0.7 -
M 10 15 4 A, B, C, D, E, F
5 20 266 SG 20 6.2 2 33 0.7 -
M 12 18.6 5 A, B, C, D, E, F
5 25 266 SG 25 6.2 2 35 0.7 -
M 16 23.5 5 A, B, C, D, E, F
Threaded shank end mill bodies
d
2
d
3
l
2
d
1
r
l
3
2 10 266 M6 10 6.2 2 22.5 0.7 -
M 6 9.75 2 A, B, C, D, E, F
3 12 266 M6 12 6.2 2 22.5 0.7 -
M 6 11.5 3 A, B, C, D, E, F
4 16 266 16 6.2 2 27.5 0.7 -
M 8 13.8 4 A, B, C, D, E, F
5 20 266 20 6.2 2 27.5 0.7 -
M 10 18 5 A, B, C, D, E, F
5 25 266 25 6.2 2 32 0.7 -
M 12 21 5 A, B, C, D, E, F
7 32 266 32 6.2 2 32 0.7 -
M 16 29 7 A, B, C, D, E, F
Plain shank end mill bodies
l
2
r
d
2
d
3
l
1
l
3
d
1
2 30 10 166 G 10 6.2 2 30 0.7 70 diam. 10 9.75 2 A, B, C, D, E, F
3 36 12 166 G 12 6.2 2 36 0.7 81 diam. 12 11.5 3 A, B, C, D, E, F
4 48 16 166 G 16 6.2 2 48 0.7 96 diam. 16 15.5 4 A, B, C, D, E, F
Accessories
21 500 P
Torx screw
A > Page
06 500 P
Torx-screwdriver
B > Page
TV 04-1
Screwdriver torque
Vario®-S with window
scale, C > Page
TV 500
Torque Vario® setter
adjusting tool
D > Page
T6 500 P
Torx interchangeable bit
for Torque Vario®
E > Page
T6 502 P, Torx Magic-
Spring compatible bit
f. Torque Vario®
F > Page
Excellent for use on small HSC machines and machining centers.
• due to high number of flutes very high feedrates are possible
• offers a real corner radius for close contour work
Slotworx® HP High feed rate cutters (HSC)
