* corner radius to be programmed
TRIGAWORX®
Size L
• allows extremely high feed rates per tooth up to fz = 3.0 mm
• better utilization of insert because of its 3 effective cutting edges
• very smooth operation, especially in deep slots or profiles
Especially for roughing operations
Indexable inserts
Catalogue no.
DIN Specification
Carbide Grade
Coating
l
s
r
M
s
l
04 74 840 WDHX 140420 SR
P40
PVTi
14.3
4.76
2
M 4.5
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
l
r
p
* l
3
l
2
l
1
d
2
d
3
z
Threaded shank end mill bodies
l
2
l
3
l
d
1
d
3
d
2
2 32 274 32 14.3 4.6* 42.5 2 -
M 16 29 2 A, B, C, D,
E, F
Shell type milling cutter bodies
l
2
l
d
1
l
3
d
3
d
2
4 52 374 52 14.3 4.6* 52.5 2 -
diam. 22 40 4 A, B, C, D, E, F
4 66 374 66 14.3 4.6* 52.5 2 -
diam. 27 48 4 A, B, C, D, E, F
5 80 374 80 14.3 4.6* 52.5 2 -
diam. 27 60 5 A, B, C, D, E, F
Accessories
45 500
Torx screw
A > Page
10 510
locking washer
B > Page
20 500
Torx-screwdriver
C > Page
TV 2-8
Screwdriver torque
Vario®-S with window
scale, D > Page
T20 500
Torx interchangeable bit
for Torque Vario®
E > Page
T20 502, Torx Magic-
Spring compatible bit
f. Torque Vario®
F > Page
