134
latest items!
available as long as stock lasts
on request
stock item, subject to confirmation
VDGT - K90°
diam. 15 - 42 mm | r1
Indexable inserts
Catalogue no.
DIN Specification
Carbide Grade
Coating
l
s
r
M
l
r
s
02 11 820 VDGT 11T210 FN
K10
polished
9
2.78
1
M 2.5
02 11 860 VDGT 11T210 FN
K10
PVTi
9
2.78
1
M 2.5
02 11 860 D VDGT 11T210 FN
K10
PVDiaN
9
2.78
1
M 2.5
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
l
r
l
3
l
2
l
1
d
2
d
3
z
DuoPlug®
d
1
d
3
r
l
2
l
l
3
d
2
16 261 SG 16 9 1 38 4 -
M 10 15 2 A, B, C, D, E
20 261 SG 20 9 1 39.5 4 -
M 12 18.5 2 A, B, C, D, E
25 261 SG 25 9 1 42.5 4 -
M 16 23.5 3 A, B, C, D, E
Threaded shank end mill bodies
d
2
d
3
d
1
l
2
r
l
l
3
15 261 15 9 1 35.5 4 -
M 8 13.8 2 A, B, C, D, E
16 261 16 9 1 35 4 -
M 8 13.8 2 A, B, C, D, E
20 261 20 9 1 35.5 4 -
M 10 18 2 A, B, C, D, E
25 261 25 9 1 40 4 -
M 12 21 3 A, B, C, D, E
32 261 32 9 1 47.5 4 -
M 16 29 4 A, B, C, D, E
42 261 42 9 1 42.5 4 -
M 16 29 5 A, B, C, D, E
Accessories
25 500
Torx screw
A > Page
07 500
Torx-screwdriver
B > Page
TV 04-1
Screwdriver torque
Vario®-S with window
scale, C > Page
T7 500
Torx interchangeable bit
for Torque Vario®
D > Page
T7 502
Torx MagicSpring compati-
ble bit f. Torque Vario®
E > Page
These milling cutters are especially suitable for milling aluminium, copper, plastics and
graphite. It allows very easy cutting and very high cutting speeds and feed rates.
Only for roughing and pre-finishing operations!
VDGT - k93° Cutters for non-ferrous materials
