131
major application
minor application
roughing
pre-finishing
finishing
XDHW 10
diam. 25 - 80 mm | r1
Universal milling cutters for finishing and profile milling with small radii.
• particularly smooth operating in corners and pockets
• low energy consumption
Indexable inserts
Catalogue no.
DIN Specification
Carbide Grade
Coating
l
s
r
M
04 79 835 XDHW 10T310 MOT
HSC 05
PVTi
10
3.97
1
M 3.5
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
l
r
l
3
l
2
l
1
d
2
d
3
z
Threaded shank end mill bodies
r
l
2
l
l
3
d
3
d
2
d
1
2 25 291 25 10 1 32 -
-
M 12 21 2 A, B, C, D, E
3 30 291 30 10 1 32 -
-
M 12 21 3 A, B, C, D, E
3 35 291 35 10 1 42 -
-
M 16 29 3 A, B, C, D, E
4 42 291 42 10 1 42 -
-
M 16 29 4 A, B, C, D, E
Shell type milling cutter bodies
d
3
d
2
l
l
2
d
1
r
l
3
5 52 391 52 10 1 53 -
-
diam. 22 40 5 A, B, C, D, E
6 66 391 66 10 1 52 -
-
diam. 27 52 6 A, B, C, D, E
7 80 391 80 10 1 52 -
-
diam. 27 52 7 A, B, C, D, E
Accessories
35 500
Torx screw
A > Page
15 500
Torx-screwdriver
B > Page
TV 2-8
Screwdriver torque
Vario®-S with window
scale, C > Page
T15 500
Torx interchangeable bit
for Torque Vario®
D > Page
T15 502
Torx MagicSpring compati-
ble bit f. Torque Vario®
E > Page
