VDGT - K93°
diam. 15 - 42 mm | r1
Indexable inserts
Catalogue no.
DIN Specification
Carbide Grade
Coating
l
s
r
M
l
r
s
02 11 820 VDGT 11T210 FN
K10
polished
9
2.78
1
M 2.5
02 11 860 VDGT 11T210 FN
K10
PVTi
9
2.78
1
M 2.5
02 11 860 D VDGT 11T210 FN
K10
PVDiaN
9
2.78
1
M 2.5
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
l
r
l
3
l
2
l
1
d
2
d
3
z
DuoPlug®
d
1
d
3
r
l
2
l
l
3
d
2
16 261-3 SG 16 9 1 38 4 -
M 10 15 2 A, B, C, D, E
20 261-3 SG 20 9 1 39.5 4 -
M 12 18.5 2 A, B, C, D, E
25 261-3 SG 25 9 1 42.5 4 -
M 16 23.5 3 A, B, C, D, E
Threaded shank end mill bodies
d
2
d
3
d
1
l
2
r
l
l
3
15 261-3 15 9 1 35 4 -
M 8 13.8 2 A, B, C, D, E
16 261-3 16 9 1 35.5 4 -
M 8 13.8 2 A, B, C, D, E
20 261-3 20 9 1 35.5 4 -
M 10 18 2 A, B, C, D, E
25 261-3 25 9 1 40 4 -
M 12 21 3 A, B, C, D, E
32 261-3 32 9 1 47.5 4 -
M 16 29 4 A, B, C, D, E
42 261-3 42 9 1 42.5 4 -
M 16 29 5 A, B, C, D, E
Accessories
25 500
Torx screw
A > Page
07 500
Torx-screwdriver
B > Page
TV 04-1
Screwdriver torque
Vario®-S with window
scale, C > Page
T7 500
Torx interchangeable bit
for Torque Vario®
D > Page
T7 502
Torx MagicSpring compati-
ble bit f. Torque Vario®
E > Page
These milling cutters are especially suitable for milling aluminium, copper, plastics and
graphite. It allows very easy cutting and very high cutting speeds and feed rates.
These inserts have a 3° clearance (kappa 93°) - a design specially for milling vertical
walls.
Only for roughing and pre-finishing operations!
VDGT - k93° Cutters for non-ferrous materials
