159
P M
K
N S
H
0.05 - 0.5
0.05 - 1.2
10
2.5
0.5
0.05 - 0.4
0.05 - 1.3
12
2.5
0.5
0.05 - 0.55
0.05 - 1.5
16
3.0
1.0
0.05 - 0.55
0.05 - 1.8
20
3.0
1.0
0.1 - 0.75
0.05 - 0.5
10
2.5
-
0.1 - 0.9
0.1 - 0.6
12
2.5
-
0.15 - 1.2
0.1 - 0.8
16
3.0
-
0.15 - 1.5
0.1 - 1.0
20
3.0
-
K10 PPTi
major application
minor application
roughing
pre-finishing
finishing
Machining types
Connection types
Sizes
Page
Cutting materials
Carbide grade
Coating
ISO standard
feed per tooth | d.o.c.
a
p
(mm)
f
z
(mm)
length
d (mm)
thickness
s (mm)
radius
r (mm)
UNIWORX
®
PLUS
- CORNER RADIUS - /
HIGH-FEED MILLING CUTTER
Universal milling cutter with a maximum range of variations for fine machining
uu
Innovative tool for steel roughing and finishing
uu
Roughing, residual material machining with
high-feed cutting inserts in steel
uu
Precision-ground angular radius plates for
high-precision finishing
uu
Asymmetric contact surfaces for error-free positioning
uu
Unique coolant supply system with fan port
across the insert
diam. 10-20 mm, r0.5 | r1.0 160
diam. 10-20 mm, HF
163
Corner radius
milling cutter
High-feed
milling cutter
