164
latest items!
available as long as stock lasts
on request
stock item, subject to confirmation
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
d r
p
* l
3
l
2
l
1
d
2
d
3
z
Plain shank end mill bodies
d
3
l
1
l
3
d
1
d
2
r
40 10 115 G 10 10 0.5 40 -
-
diam. 10 9.8 2 A, D, I, J, M
48 12 115 G 12 12 0.5 48 -
-
diam. 12 11.8 2 B, E, G, K, N
64 16 115 G 16 16 1 64 -
-
diam. 16 13.8 2 C, F, H, L, O
80 20 115 G 20 20 1 80 -
-
diam. 20 18 2 C, F, H, L, O
Accessories
30 530
locating screw
A > Page ???
35 530
locating screw
B > Page ???
50 530
locating screw
C > Page ???
08 500
Torx-screwdriver
D > Page
10 500
Torx-screwdriver
E > Page
20 500
Torx-screwdriver
F > Page
TV 1-5
Screwdriver torque Va-
rio®-S with window scale
G > Page
TV 2-8
Screwdriver torque
Vario®-S with window
scale, H > Page
TV 08-2
Screwdriver torque
Vario®-S with window
scale, I > Page
T8 500
Torx interchangeable bit
for Torque Vario®
J > Page
T10 500
Torx interchangeable bit
for Torque Vario®
K > Page
T20 500
Torx interchangeable
bit for Torque Vario®
L > Page
T8 502
Torx MagicSpring compati-
ble bit f. Torque Vario®
M > Page
T10 502
Torx MagicSpring
compatible bit f. Torque
Vario®l N > Page
T20 502
Torx MagicSpring compa-
tible bit f. Torque Vario®
O > Page
Indexable inserts
Catalogue no.
DIN Specification
Carbide Grade
Coating
d
s
r
M
s
d
r
15 10 8060 HF
XOGX 1025 ER
K10
PPTi
10
2.5
-
M 3.0
15 12 8060 HF
XOGX 1225 ER
K10
PPTi
12
2.5
-
M 3.5
15 16 8060 HF
XOGX 1630 ER
K10
PPTi
16
3
-
M 5.0
15 20 8060 HF
XOGX 2030 ER
K10
PPTi
20
3
-
M 5.0
UNIWORX® PLUS Corner radius- / High feed rate cutters
