28
latest items!
available as long as stock lasts
on request
stock item, subject to confirmation
Material
steel
stainless steel
cast iron
non-ferrous
materials
high-temperature
alloys
hardened steel
Quality
Coating
Feed per
tooth | d.o.c.
P40 PVSR
f
z
(mm)
a
p
(mm)
0,08-0,55
0,1-6
-
-
-
-
-
K10 PVTi
f
z
(mm)
a
p
(mm)
-
-
0,1-0,55
0,1-6
-
-
-
M40 PVST
f
z
(mm)
a
p
(mm)
-
0,08-0,3
0,1-4
-
-
0,08-0,2
0,1-3
-
PLANWORX®
diam 40 - 250 mm
Indexable inserts
Catalogue no.
DIN Specification
Carbide Grade
Coating
l
s
r
M
S
r
l
05 31 842 SNMX 135408 ER
P40
PVSR
13
5.4
0.8
M 4.0
05 31 862 SNMX 135408 ER
K10
PVTi
13
5.4
0.8
M 4.0
05 31 896 SNMX 135408 ER
M40
PVST
13
5.4
0.8
M 4.0
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
l
r
l
3
l
2
l
1
d
2
d
3
z
Shell type milling cutter bodies
d
d
1
l
2
l
3
d
3
d
2
4 40 331 40 13 0.8 42 6.7 -
diam. 22 40 4 A, B, C, D, E
5 50 331 50 13 0.8 52 6.7 -
diam. 27 48 5 A, B, C, D, E
6 63 331 63 13 0.8 52 6.7 -
diam. 27 60 6 A, B, C, D, E
8 80 331 80 13 0.8 52 6.7 -
diam. 32 70 8 A, B, C, D, E
10 100 331 100 13 0.8 52 6.7 -
diam. 40 90 10 A, B, C, D, E
12 125 331 125 13 0.8 52 6.7 -
diam. 40 90 12 A, B, C, D, E
14 160 331 160 13 0.8 52 6.7 -
diam. 40 120 14 A, B, C, D, E
16 200 331 200 13 0.8 52 6.7 -
diam. 60 160 16 A, B, C, D, E
20 250 331 250 13 0.8 52 6.7 -
diam. 60 160 20 A, B, C, D, E
Accessories
40 505 P
Torx screw
A > Page
15 500 P
Torx-screwdriver (Tor-
x-Plus)
B > Page
TV 2-8
Screwdriver torque
Vario®-S with window
scale, +C > Page
T15 500 P
Torx interchangeable bit
for Torque Vario®
D > Page
T15 502 P
Torx MagicSpring compati-
ble bit f. Torque Vario®
E > Page
Face-milling cutter with maximum chipping depth of 6 mm, negative axial rake angle
for square inserts with eight cutting edges. Internal coolant supply up to tool diameter
125mm. Differential pitch for smooth running.
Feed per tooth (fz) | d.o.c. (ap)
Planworx® Face milling cutters
