latest items!
available as long as stock lasts
on request
stock item, subject to confirmation
DR - SPINWORX
®
P - polished rake face for machining of Non-ferrous materials
Order number key:
SPINWORX
®
Inserts
Example::
DR 10 - 8 C 7 - P
Tool type
Insert size
[diam. mm]
Identification feature
Code | Quality | Material suitability
Geometry
Order number key:
SPINWORX
®
Milling cutter bodies
Example:
DR10-025-E12-03
Tool type
Tool type
diam. mm
[d]
Nominal diameter
mm
[d
1
]
Type of connection
Connection size
diam. mm [d
2
]
E - Threaded shank end mill body
A - Shell-type milling cutter body
No. of teeth
DR - SPINWORX
®
stainless steel /
high-temperature alloys
steel / cast iron /
hardened steel < 60 HRC
stainless steel /
high-temperature alloys
steel / casst iron
steel / casst iron
steel / casst iron /
hardened steel < 48 HRC
sintered without chip-breaker groove
sintered with chip-breaker groove
grinded without chip-breaker groove
grinded with chip-breaker groove
Clearance angle /
Design
SPINWORX
®
COPY CUTTERS
The order number keys for milling cutter bodies and inserts
