SPINWORX®
r5 - diam. 20 - 52 mm, 7° positive rake angle
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
d r
l
3
l
2
l
1
d
2
d
3
z
Threaded shank end mill bodies
d
2
d
d
1
d
3
l
2
l
3
DR10-020-E10-02 20 10 5 29 2.5 -
M 10 18 2 A, B, C, D
DR10-025-E12-03 25 10 5 32.5 1.5 -
M 12 21 3 A, B, C, D
DR10-025-E12-04 25 10 5 32.5 1.5 -
M 12 21 4 A, B, C, D
DR10-030-E12-04 30 10 5 33 2.5 -
M 12 21 4 A, B, C, D
DR10-030-E16-04 30 10 5 43 2.5 -
M 16 29 4 A, B, C, D
DR10-032-E16-04 32 10 5 43 2.5 -
M 16 29 4 A, B, C, D
DR10-032-E16-05 32 10 5 43 2.5 -
M 16 29 5 A, B, C, D
DR10-035-E16-05 35 10 5 43 2.5 -
M 16 29 5 A, B, C, D
DR10-042-E16-06 42 10 5 43 2.5 -
M 16 29 6 A, B, C, D
Shell-type milling cutter bodies
l
3
d
3
l
2
d
1
d
d
2
DR10-040-A16-05 40 10 5 43 2.5 -
diam. 16 35 5 A, B, C, D
DR10-042-A16-05 42 10 5 43 2.5 -
diam. 16 35 5 A, B, C, D
DR10-042-A16-06 42 10 5 43 2.5 -
diam. 16 35 6 A, B, C, D
DR10-052-A22-07 52 10 5 52 2.5 -
diam. 22 40 7 A, B, C, D
Accessories
T10-1,4NM
Torque Fix® - S torque
screwdriver
A > Page
T10 500
Torx interchangeable
bit for Torque Vario®
B > Page
T10 502
Torx MagicSpring compa-
tible bit f. Torque Vario®
C > Page
Z 00043
HTC ceramic paste WS
600 005
D > Page
The all-rounders in the SPINWORX series.
• wide range of use for almost all areas of application
• effective use of the cutting edge
• with specially adapted primary and secondary coolant supply.
• low power consumption, high chip removal rate.
CAUTION! PLEASE NOTE!
For optimum results with the SPINWORX®-tooling system we recommend using internal
coolant supply air, emulsion or MQL for chip removal in the tool! Wet machining up to
max speed Vc of 140 m/min!
SPINWORX® Copy cutters
