* corner radius to be programmed
QUADWORX®
Size XL
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
l
r
p
* l
3
l
2
l
1
d
2
d
3
z
Threaded shank end mill bodies
l
2
l
3
d
3
d
2
r
p
l
d
1
2 32 251 32 13 3.3* 42 1.5 -
M 16 29 2 A, B, C, D, E, F
3 35 251 35 13 3.3* 42 1.5 -
M 16 29 3 A, B, C, D, E, F
Shell type milling cutter bodies
l
2
d
1
l
l
3
d
3
r
p
d
2
4 40 351 40 13 3.3* 42.5 2.5 -
diam. 16 35 4 A, C, D, E, F, G
4 42 351 42 13 3.3* 42.5 2.5 -
diam. 16 35 4 A, C, D, E, F, G
4 50 351 50 13 3.3* 50 2.5 -
diam. 22 40 4 A, D, E, F, G
5 50 351 50 13 3.3* 50 2.5 -
diam. 22 40 5 A, D, E, F, G
4 50 351 52 13 3.3* 50 2.5 -
diam. 22 48 4 A, D, E, F, G
5 52 351 52 13 3.3* 50 2.5 -
diam. 22 48 5 A, D, E, F, G
6 63 351 63 13 3.3* 53 2.5 -
diam. 27 48 6 A, D, E, F, G
6 66 351 66 13 3.3* 53 2.5 -
diam. 27 48 6 A, D, E, F, G
6 80 351 80 13 3.3* 53 2.5 -
diam. 27 60 6 A, D, E, F, G
8 80 351 80 13 3.3* 53 2.5 -
diam. 27 60 8 A, D, E, F, G
7 100 351 100 13 3.3* 53 2.5 -
diam. 32 70 7 A, B, D, E, F, G
9 100 351 100 13 3.3* 53 2.5 -
diam. 32 70 9 A, B, D, E, F, G
Accessories
40 505 K
Torx screw
A > Page
M16X35
screw short head
B > Page
GWSTPS8ISK
hexagon socket set screw
C > Page
15 500 P
Torx-screwdriver (Tor-
x-Plus)
D > Page
TV 2-8
Screwdriver torque Va-
rio®-S with window scale
E > Page
T15 500 P
Torx interchangeable
bit for Torque Vario®
F > Page
T15 502 P
Torx MagicSpring compati-
ble bit f. Torque Vario®
G > Page
• four cutting edges per insert for extremely efficient operations
• very big metal removal rates and extremely easy cutting
• as a standard, every tool has internal coolant supply
• allows extremely high feed rates per tooth up to fz = 2.8 mm
Quadworx® High feed rate cutters (HSC)
176
