Plunging
d
1
X
Cutter diam.
d1
D
p
X
max
32
11.8
1.5
35
14.8
1.5
40
19.8
2.5
42
21.8
2.5
50
29.8
2.5
52
31.8
2.5
63
42.8
2.5
66
45.8
2.5
80
59.8
2.5
100
79.8
2.5
Extended operation data
Ramping
Y
d
1
X
α
Cutter diam.
d1
α
°
y
32
<9
8.8
35
<7,0
11.8
40
<6,5
16.8
42
<5,8
18.8
50
<4,1
26.8
52
<3,7
28.8
63
<2,6
39.8
66
<2,4
42.8
80
<1,8
56.8
100
<1,2
72.8
Helix
D min/max
d
1
Cutter diam.
d1
D
min
D
max
32
40.8
62
35
46.8
68
40
56.8
78
42
60.8
82
50
76.8
98
52
80.8
102
63
102.8
124
66
108.8
130
80
136.8
158
100
176.8
198
Technical information
