Plunging
d
1
X
Cutter diam.
d1
D
p
X
max
35
17.7
2.5
42
24.7
2.5
52
34.7
2.5
66
48.7
2.5
80
62.7
2.5
Ramping
Y
d
1
X
α
Cutter diam.
d1
α
°
y
35
<8,3
17
42
<5,9
24
52
<4,2
34
66
<2,9
48
80
<2,3
62
Helix
D min/max
d
1
Cutter diam.
d1
D
min
D
max
35
52
70
42
66
84
52
86
104
66
114
132
80
142
160
Extended operation data
Technical information
175
