COATING SUMMARY
Inserts
Description
PVTi
TiAIN
blue/grey
up to 850°
2 to 4
PVGM
-
gold
up to 650°
2 to 3,5
PVDiaN Diamond-coating, normal
dull grey
up to 600°
6 to 8
PVFN
PVFN
blue/grey
up to 950°
2 to 4
PVTiH
TiAlN Multilayer
violet/brown
up to 1100°
4 to 5
PVGO
TiAlN + TiN
yellow/gold
900°
2 to 4,5
PVML
TiAlSiN
gold
800° to 850°
2,5 to 5
PVSR
-
black
up to 1000°
4 to 6,5
Colour
Vickers
Hardness HV
Maximum Tem-
perature in
Centigrade
Type of
Coating
Thickness of
Coating in
µ
m
PVST
ALTiN
blue/grey
up to 950°
2 to 4
PCSR
PCTC
PPTi
black
silver
black / gray
up to 900°
up to 1000°
up to 900°
8 to 10
6 to 7
3 to 5
Coating summary - inserts
