* corner radius to be programmed
QUADWORX®
Size L
• four cutting edges per insert for extremely efficient operations
• very big metal removal rates and extremely easy cutting
• as a standard, every tool has our patent protected incorporated insert seats and
internal coolant supply
• allows extremely high feed rates per tooth up to fz = 2.5 mm
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
l
r
p
* l
3
l
2
l
1
d
2
d
3
z
Threaded shank end mill bodies
l
2
l
3
d
3
d
2
r
p
l
d
1
3 35 249 35 10 2.3* 42 2.5 -
M 16 29 3 A, B, C, D, E
4 42 249 42 10 2.3* 42 2.5 -
M 16 29 4 A, B, C, D, E
Shell type milling cutter bodies
l
2
d
1
l
l
3
d
3
r
p
d
2
4 42 349 42 10 2.3* 42 2.5 -
diam. 16 35 4 A, C, E, F, H
5 52 349 52 10 2.3* 52 2.5 -
diam. 22 40 5 B, D, E, G, I
7 66 349 66 10 2.3* 52 2.5 -
diam. 27 48 7 B, D, E, G, I
8 80 349 80 10 2.3* 52 2.5 -
diam. 27 60 8 B, D, E, G, I
Accessories
40 505 K
Torx screw
A > Page
40 505 P
Torx screw
B > Page
15 500
Torx-screwdriver
C > Page
15 500 P
Torx-screwdriver (Tor-
x-Plus)
D > Page
TV 2-8
Screwdriver torque Va-
rio®-S with window scale
E > Page
T15 500
Torx interchangeable
bit for Torque Vario®
F > Page
T15 500 P
Torx interchangeable bit for
Torque Vario®
G > Page
T15 502
Torx MagicSpring
compatible bit f. Torque
Vario®, H > Page
T15 502 P
Torx MagicSpring compa-
tible bit f. Torque Vario®
I > Page
173
