* corner radius to be programmed
QUADWORX®
Size M
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
l
r
p
* l
3
l
2
l
1
d
2
d
3
z
DuoPlug®
l
1
d
3
d
1
l
3
d
2
l
r
p
2 22 248 SG 22 9 1.5* 35.5 1.5 -
M 12 18.5 2 A, B, C, D, E
3 25 248 SG 25 9 1.5* 40 1.5 -
M 16 23.5 3 A, B, C, D, E
Threaded shank end mill bodies
l
2
l
3
d
3
d
2
r
p
l
d
1
2 22 248 22 9 1.5* 29 1.5 -
M 10 18 2 A, B, C, D, E
3 25 248 25 9 1.5* 33 1.5 -
M 12 21 3 A, B, C, D, E
4 30 248 30 9 1.5* 42 1.5 -
M 16 29 4 A, B, C, D, E
4 32 248 32 9 1.5* 42 1.5 -
M 16 29 4 A, B, C, D, E
4 35 248 35 9 1.5* 42 1.5 -
M 16 29 4 A, B, C, D, E
5 35 248 35 9 1.5* 42 1.5 -
M 16 29 5 A, B, C, D, E
5 42 248 42 9 1.5* 42 1.5 -
M 16 29 5 A, B, C, D, E
Shell type milling cutter bodies
l
2
d
1
l
l
3
d
3
r
p
d
2
5 42 348 42 9 1.5* 42.5 1.5 -
diam. 16 35 5 A, B, C, D, E
6 52 348 52 9 1.5* 52.5 1.5 -
diam. 22 40 6 A, B, C, D, E
Accessories
30 500
Torx screw
A > Page
10 500
Torx-screwdriver
B > Page
TV 1-5
Screwdriver torque
Vario®-S with window
scale, C > Page
T10 500
Torx interchangeable bit
for Torque Vario®
D > Page
T10 502
Torx MagicSpring compati-
ble bit f. Torque Vario®
E > Page
• four cutting edges per insert for extremely efficient operations
• very big metal removal rates and extremely easy cutting
• as a standard, every tool has our patent protected incorporated insert seats and
internal coolant supply
• allows extremely high feed rates per tooth up to fz = 2.2 mm
Quadworx® High feed rate cutters (HSC)
