Technical information
Plunging
d
1
X
Cutter diam.
d1
D
p
X
max
22
7.1
1.5
25
9.8
1.5
30
14.7
1.5
32
16.7
1.5
35
19.7
1.5
42
26.5
1.5
52
36.5
1.5
Extended operation data
Ramping
Y
d
1
X
α
Cutter diam.
d1
α
°
y
22
<13,7
6
25
<9,2
9
30
<5,8
14
32
<4,9
16
35
<4,3
19
42
<3,1
26
52
<2,1
36
Helix
D min/max
d
1
Cutter diam.
d1
D
min
D
max
22
28.5
44
25
34.5
50
30
44.5
60
32
48.5
64
35
54.5
70
42
68.5
84
52
88.5
104
Quadworx® High feed rate cutters (HSC)
